Step-by-Step Guide: Install a Water Butt and Gutter Diverter - Frankton's

Step-by-Step Guide: Install a Water Butt and Gutter Diverter

Installing a water butt and gutter diverter is a fantastic way to collect rainwater and reduce water consumption, all while benefiting the environment. By harnessing this readily available resource, you can water your plants, wash your car, or even use it for non-potable household tasks. In this article, we will provide you with a comprehensive, step-by-step guide on how to install a water butt and gutter diverter, enabling you to embrace sustainable water management practices.

Materials Needed:

1. Water butt (choose a size suitable for your needs)
2. Gutter diverter kit (typically includes diverter, hose, and fittings)
3. Downpipe connector or rainwater filter (optional, depending on your setup)
4. Spirit level
5. Tape measure
6. Saw
7. Pencil or marker
8. Adjustable spanner or pliers
9. Screwdriver
10. Sealant (if required)

Step 1: Choose the Location

Select a suitable location for your water butt. It should be close to a downpipe or guttering system to collect rainwater efficiently. Ensure the area is level and can support the weight of the water butt when full. Also, consider accessibility for future maintenance and water extraction.

Step 2: Prepare the Gutter

Identify the section of the downpipe or gutter where you want to install the diverter. Measure and mark the appropriate height for installation, typically a few inches above the top of the water butt. Use a spirit level to ensure accuracy.


Step 3: Install the Gutter Diverter

Follow the manufacturer's instructions to install the gutter diverter. Generally, you will need to cut a section out of the downpipe or gutter using a saw, as marked in the previous step. Insert the diverter into the gap and secure it using screws or clips provided in the kit. Ensure it is securely attached and aligned properly.


Step 4: Attach the Hose

Connect one end of the hose provided with the diverter kit to the outlet of the diverter. Use an adjustable spanner or pliers to tighten the fittings, ensuring a watertight connection. The other end of the hose should be attached to the water butt's inlet, typically located near the top.


Step 5: Secure the Water Butt

Place your water butt in the chosen location and ensure it is level. If the surface is uneven, use shims or a sturdy platform to create stability. Some water butts come with a stand or wall brackets for added support and elevation.


Step 6: Test the Setup

With the installation complete, turn on the water supply to your gutter system. Observe if water is flowing into the water butt through the diverter and hose. Check for any leaks or drips in the connections and rectify them if necessary. Adjust the position of the diverter or hose if water is not flowing properly.


Step 7: Optional: Additional Filtering

If desired, you can install a downpipe connector or rainwater filter between the diverter and the water butt. These additional components help filter out debris and leaves, ensuring cleaner water collection and reducing the risk of clogging.


Step 8: Maintenance and Usage

Regularly inspect your water butt, diverter, and connections for any signs of damage or leaks. Clean the gutter and downpipe periodically to prevent blockages. When using the collected rainwater, avoid using it for drinking or cooking purposes unless you have a filtration system in place.


Conclusion:

Installing a water butt and gutter diverter provides a sustainable and eco-friendly solution for water conservation. By following these step-by-step instructions, you can effectively collect rainwater and reduce your reliance on the
